High-Speed Row Welding Machine Precision Joining for Metal Sheets

High-Speed Row Welding Machine Precision Joining for Metal Sheets

high-speed metal sheet welder

precision row welding machine

spot welder for metal sheets

Place of Origin:

China

Marca:

HWASHI

Certificação:

CE/CCC/ISO

Model Number:

WL-CD-5K

Contacte-nos
Peça umas citações
Detalhes do produto
Product Name:
High-Speed Row Welding Machine Precision Joining for Metal Sheets
Warranty:
12months
Condition:
New
Certificate:
CE/CCC/ISO
Service Life:
8-10 years
Cooling Water:
30L/min
Termos do pagamento & do transporte
Minimum Order Quantity
1 set
Preço
Negociável
Packaging Details
sea worthy wooden package
Delivery Time
7-30 working days after received your payment
Payment Terms
L/C, T/T
Supply Ability
50 sets per month
Descrição do produto

Product Description

High-Speed Row Welding Machine Precision Joining for Metal Sheets 0
Product Description

HWASHI Wire Frame T Butt Welding Machine


High-Speed Row Welding Machine Precision Joining for Metal Sheets 1High-Speed Row Welding Machine Precision Joining for Metal Sheets 2
High-Speed Row Welding Machine Precision Joining for Metal Sheets 3

Product description
The equipment requires a wire diameter of 2.5mm-8mm and a maximum size range of 800mmX1300mm. The design uses double-head T-butt welding. Welding both ends of the iron wire at the same time. Welding structure adopts the butt-welding structure before and after pressing up and down.
While the machine head is fixed, the size can be adjusted according to product requirements. A set of industrial frequency pulse AC 75K is used as the welding power source, and the welding is stable, which guarantees no false soldering and desoldering.
This equipment realizes simultaneous butt welding of both ends of wire frame and iron wire, and can adapt to wire frame welding of different sizes, improving product quality and production efficiency, reducing production costs, solving the defects of unstable quality and low production efficiency of manual operations, Higher productivity and automation

High-Speed Row Welding Machine Precision Joining for Metal Sheets 4



High-Speed Row Welding Machine Precision Joining for Metal Sheets 5High-Speed Row Welding Machine Precision Joining for Metal Sheets 6

No.
Item
Parameters
1
Input Power
50KVA
2
Input Voltage
380V Single-phase 50Hz
3
Input Current
135A
4
Output Voltage
AC5.6V
5
Max Short Circuit Current
21000A
6
Welding Models
16 types
7
Welding Cylinder
¢50x2-80mm
8
Pushing Cylinder
¢80-80mm
9
Dimension (L*W*H)
1000x1000x1500mm
10
Weight
120kg
